Security API for RACF (SEAR) - A standardized JSON interface for RACF that enables seamless exploitation by programming languages that have a foreign language interface for C/C++ and native or third-party JSON support. SEAR is a fork of RACFu, an abandoned RACF API created by IBM.
SEAR is currently in Alpha, meaning that some core functionality may still be missing, unstable, and or may still need more thorough testing.
- SEAR encodes the data it passes to RACF in Code Page
IBM-1047.- If you are entering information with special or national characters, users viewing or altering this information from terminals using different or international codepages may see unexpected data.
- Please consult a list of invariant characters to use for such information if this applies to you.
Mission Statement
As automation becomes more and more prevalent, the need to manage the security environment programmatically increases. On z/OS that means managing a security product like the IBM Resource Access Control Facility (RACF). RACF is the primary facility for managing identity, authority, and access control for z/OS. There are more than 50 callable services with assembler interfaces that are part of the RACF API. The complete set of interfaces can be found in the IBM documentation.
While there are a number of languages that can be used to manage RACF, (from low level languages like Assembler to higher level languages like REXX), the need to be able to easily exploit RACF management functions using existing industry standard programming languages and even programming languages that don’t exist yet is paramount. The SEAR project is focused on making RACF management functions available to all programming languages that have native or third-party JSON support and a foreign language interface for C/C++. This will make it easier to pivot to new tools and programming languages as technology, skills, and business needs continue to evolve in the foreseeable future.
Minimum z/OS & Language Versions
All versions of z/OS and the IBM Open Enterprise SDK for Python that are fully supported by IBM are supported by SEAR.
Dependencies
- R_SecMgtOper (IRRSMO00): Security Management Operations.
- R_Admin (IRRSEQ00): RACF Administration API.
- R_Datalib (IRRSDL64): RACF Certificate data library.
- RACF Subsystem Address Space: This is a dependency for both IRRSMO00 and IRRSEQ00. More information can be found in the IBM documentation.
See the dependencies page for required PTFs and other dependencies
Authorizations
The following authorizations are required in order to exploit some of the basic the functionality that SEAR provides.
| Access | General Resource Profile | Class | Functionality |
READ | IRR.RADMIN.LISTUSER | FACILITY | Extract User Profiles |
READ | IRR.RADMIN.LISTGRP | FACILITY | Extract Group Profiles |
READ | IRR.RADMIN.RLIST | FACILITY | Extract General Resource Profiles |
READ | IRR.RADMIN.LISTDSD | FACILITY | Extract Data Set Profiles |
READ | IRR.RADMIN.SETROPTS.LIST | FACILITY | List RACF Options |
READ | IRR.IRRSMO00.PRECHECK | XFACILIT | Add, Alter and Delete Profiles |
UPDATE | <userid>.IRRSMO00 | SURROGAT | Run Add, Alter, and Delete Commands as a Specific Userid |
See the full list in the Required authorizations page, as it contains information on authorizations required for certificate and keyring requests as well as more information in general.
Installing the Python interface
You may also optionally Download SEAR From GitHub.
You can install SEAR with the following command:
pip install pysear
If the command fails you might need to set up artifactory access to your mainframe or download SEAR from PyPi or GitHub.
Testing SEAR
After you have installed it you can test it from a z/OS Unix shell environment
python
>>> from sear import sear
>>> result = sear({"operation": "extract", "admin_type": "user", "userid": "SQUIDWRD"})
>>> result.result
{'profile': {'base': {'base:audit_logging': False, 'base:read_only_auditor': False, 'base:auditor': False, 'base:automatic_dataset_protection': False, 'base:create_date': '09/13/24', 'base:default_group': 'SYS1', 'base:group_connections': [{'base:group_connection_auditor': False, 'base:group_connection_automatic_dataset_protection': False, 'base:group_connection_create_date': '09/13/24', 'base:group_connection_dataset_access': False, 'base:group_connection_group': 'SYS1', 'base:group_connection_last_connect_date': None, 'base:group_connection_last_connect_time': None, 'base:group_connection_operations': False, 'base:group_connection_owner': 'LEONARD', 'base:group_connection_resume_date': None, 'base:group_connection_revoke_date': None, 'base:group_connection_revoked': False, 'base:group_connection_special': False, 'base:group_connection_universal_access': 'NONE', 'base:group_connection_used_count': 0}], 'base:group_dataset_access': False, 'base:has_passphrase': False, 'base:has_password': False, 'base:logon_allowed_days': [{'base:logon_allowed_day': 'SUNDAY'}, {'base:logon_allowed_day': 'MONDAY'}, {'base:logon_allowed_day': 'TUESDAY'}, {'base:logon_allowed_day': 'WEDNESDAY'}, {'base:logon_allowed_day': 'THURSDAY'}, {'base:logon_allowed_day': 'FRIDAY'}, {'base:logon_allowed_day': 'SATURDAY'}], 'base:logon_allowed_time': 'ANYTIME', 'base:mfa_password_fallback': False, 'base:name': 'SQUIDWARD', 'base:operations': False, 'base:owner': 'LEONARD', 'base:passphrase_change_interval': 0, 'base:passphrase_enveloped': False, 'base:password_change_interval': 186, 'base:password_enveloped': False, 'base:protected': True, 'base:restrict_global_access_checking': False, 'base:revoked': False, 'base:special': False}, 'omvs': {'omvs:home_directory': '/u/squidwrd', 'omvs:uid': 24}}, 'return_codes': {'racf_reason_code': 0, 'racf_return_code': 0, 'sear_return_code': 0, 'saf_return_code': 0}}
Architecture
Just because a Programming Language Exploiter is shown on this architecture diagram does not mean that there is or will be an interface created, maintained, and distributed by the Mainframe Renewal Project for that programming language. The interfaces currently maintained and distributed by the MRP can be found in the interfaces page.
flowchart TB
subgraph s1["C/C++"]
n1["Security API for RACF (SEAR)"]
n2@{ label: "<span style=\"padding-left:\">IRRSMO00 (64-bit OSLINK EBCDIC)</span>" }
n5["Setropts, user, group, dataset, and resource operation (Add, alter, delete)"]
n11["IRRSDL64 (64 bit OSLINK EBCDIC)"]
n12["Certificate management operation (Add, extract, and delete)"]
n7@{ label: "<span style=\"padding-left:\">RRSF, setropts, user, group, dataset, and resource operation (Extract and search)</span>" }
end
subgraph s2["HLASM"]
n4["IRRSEQ00 (31-bit OSLINK EBCDIC)"]
end
subgraph s3["SEAR project"]
s1
s2
n3@{ label: "<span style=\"padding-left:\">JSON (UTF-8)</span>" }
A["SEAR Python JSON interface"]
n6["Binary (EBCDIC)"]
n8["Binary (EBCDIC)"]
n9["RACF"]
n10["SAF"]
n14@{ label: "<span style=\"padding-left:\">JSON (UTF-8)</span>" }
n13@{ label: "<span style=\"padding-left:\">SEAR Golang JSON interface (future interface)</span>" }
n16@{ label: "<span style=\"padding-left:\">JSON (UTF-8)</span>" }
n15["SEAR Java JSON interface (future interface)"]
n18@{ label: "<span style=\"padding-left:\">JSON (UTF-8)</span>" }
n17["SEAR Node.js JSON interface (future interface)"]
n19["Binary (EBCDIC)"]
n21@{ label: "<span style=\"padding-left:\">JSON (UTF-8)</span>" }
n20["SEAR C/C++ JSON interface"]
end
n23@{ label: "pyRACF (successor to IBM's pyRACF)" } --- A
n24["Ansible interface (future interface)"] --- n23
A --- n3
n3 --- n1
n1 --- n5 & n7 & n12
n5 --- n2
n2 --- n6
n6 --- n4
n7 --- n8
n8 --- n4
n10 --- n9
n4 --- n10
n12 --- n11
n13 --- n14
n14 --- n1
n15 --- n16
n16 --- n1
n17 --- n18
n18 --- n1
n11 --- n19
n19 --- n10
n20 --- n21
n21 --- n1
n25["RACSHELL (z/OS Unix RACF shell interface)"] --- n20
n1@{ shape: rounded}
n2@{ shape: rounded}
n5@{ shape: rounded}
n11@{ shape: rounded}
n12@{ shape: rounded}
n7@{ shape: rounded}
n4@{ shape: rounded}
n3@{ shape: text}
A@{ shape: rounded}
n6@{ shape: text}
n8@{ shape: text}
n9@{ shape: cyl}
n10@{ shape: rounded}
n14@{ shape: text}
n13@{ shape: rounded}
n16@{ shape: text}
n15@{ shape: rounded}
n18@{ shape: text}
n17@{ shape: rounded}
n19@{ shape: text}
n21@{ shape: text}
n20@{ shape: rounded}
n23@{ shape: rounded}
n24@{ shape: rounded}
n25@{ shape: rounded}
n1:::Class_08
n2:::Class_06
n5:::Class_07
n11:::Class_06
n12:::Class_07
n7:::Class_07
n4:::Class_06
n3:::Ash
A:::Pine
A:::Class_01
A:::Class_01
A:::Class_01
n6:::Ash
n8:::Ash
n9:::Class_05
n10:::Class_05
n14:::Ash
n13:::Pine
n13:::Class_01
n13:::Class_02
n16:::Ash
n15:::Pine
n15:::Class_01
n15:::Class_02
n15:::Class_03
n15:::Class_03
n18:::Ash
n17:::Pine
n17:::Class_01
n17:::Class_02
n17:::Class_03
n17:::Class_03
n17:::Class_04
n19:::Ash
n21:::Ash
n20:::Pine
n20:::Class_01
n20:::Class_01
n20:::Class_01
n20:::Class_09
n25:::Pine
n25:::Class_01
n25:::Class_01
n25:::Class_01
n25:::Class_09
classDef Pine stroke-width:1px, stroke-dasharray:none, stroke:#254336, fill:#27654A, color:#FFFFFF
classDef Class_02 fill:#68d7e2, color:#000000
classDef Class_03 fill:#ec2025, color:#FFFFFF, stroke:#000000
classDef Class_01 fill:#FFD600, color:#000000
classDef Class_04 fill:#417e38, color:#FFFFFF, stroke:transparent
classDef Ash stroke-width:1px, stroke-dasharray:none, stroke:#999999, fill:#EEEEEE, color:#000000
classDef Class_06 stroke:#2962FF, fill:#2962FF, color:#FFFFFF
classDef Class_05 fill:#757575, color:#FFFFFF
classDef Class_07 fill:#FF6D00, color:#FFFFFF
classDef Class_08 fill:#FFFFFF, color:#000000, stroke:#000000
classDef Class_09 fill:#00559e, stroke:transparent, color:#FFFFFF
style A stroke:none
style n13 stroke-width:2px,stroke-dasharray: 2,stroke:#FFFFFF
style n15 stroke-width:2px,stroke-dasharray: 2,stroke:#FFFFFF
style n17 stroke-width:2px,stroke-dasharray: 2,stroke:#FFFFFF
style n20 stroke:none
style n23 fill:#FFD600,stroke-width:2px,stroke-dasharray: 2,color:#000000,stroke:#FFFFFF
style n24 fill:#AA00FF,color:#FFFFFF,stroke-width:2px,stroke-dasharray: 2,stroke:#FFFFFF
style n25 stroke:none
